Hybrid and electric transport applications

Careful design, high design and assembly standard, component quality and low noise emission make Mattei air compressors the best solution for applications on electric and hybrid vehicles.



Download Catalogue

BENEFITS

Energy Savings

Mattei compressors are designed based on energy savings and they are equipped with IE3 efficiency class motors.
The low rotation speed of the air end and the 1:1 direct coupling between the electric motor and the compressor ensure energy savings of more than 15% compared to other rotary compressors.

Compact and Reliable Machines

  • Integrated design, direct coupling, low rotation speed and the limited number of moving parts make Mattei rotary vane compressors safe and reliable over time;
  • complete air end conforming to industry standards including electric motor, filters, dryers, mounting frames and air storage;
  • compact and lightweight, they meet the most demanding space requirements. Mattei compressor design is customisable for any application.

Quality Air and Low Noise Emissions

  • The three-stage oil separation ensures high quality compressed air, free of impurities and oil residues;
  • innovative patented anti-condensation system that prevents oil emulsification;
  • Mattei compressors stand out for the absence of vibrations and silent running, an essential prerogative on hybrid and electric vehicles.

Continuous operation

Mattei compressors for hybrid and electric vehicle applications ensure continuous operation without degradation of the quality of the air delivered. Operation can be continuous or in start/stop mode.

Extreme Operating Conditions

Regardless of weather or environmental conditions, Mattei compressors maintain their performance, reliability and operational safety. They are also robust and resistant to scratches and corrosion.

Simple and Economical Maintenance

Maintenance designed for the lowest life cycle cost: no maintenance is required for the first five years and it is possible to customise maintenance schedule.

Applications

  • Fully electric buses - 6/8/10/12 and 18-metre buses;
  • electric vehicles for the urban transport of “last mile” goods and people;
  • hybrid buses;
  • long-distance hybrid lorries;
  • trolley-buses.
  • RANGE



    Rated power 1.1 to 11 kW
    F.A.D. 60 to 1970 l/min
    Working pressures from 6 to 13 bar
    Voltage 12V - 3000V
    Frequency 33 - 100Hz
    Extra Custom Inverters
  • FEATURES



    Compression technology Rotary Vane
    Output 0% to 100%
    Flow 60 - 320 l/min
    Pressure from 6 to 13 bar
    Ambient Temp - 35°C + 80°C
    Sound pressure level 54 - 64 dBA
    Coupling Direct drive
    Drive Hydraulic drive
    DC Motor
    Asynchronous motors
    Permanent magnet motors
    Brushless
    Voltage 12V - 3000V
    Frequency 33 - 100 Hz
    Relative humidity Up to 98%
    Extra High efficiency intake filters
    Dryers
    Soundproofing
    Anti vibration dampers
    Custom inverters
    Anticondensation valve
